Gravity: IO Expansion Shield for LattePanda V1

Description Gravity: IO Expansion Shield for LattePanda V1 Facilitates GPIO pin breakout ensuring Arduino compatibility Supports 7~12V power supply with max output of 5A under 5V IO Includes 14 digital and 6 analog Gravity interfaces Compatible with LattePanda V1 and numerous sensors Measures 70mm x 68mm for compact integration The Gravity: IO Expansion Shield for LattePanda V1 facilitates the breakout of all GPIO pins, ensuring compatibility with standard Arduino devices without interfering with other ports on the LattePanda. Each pin includes VCC and GND power ports, supporting the Gravity-3Pin Color coded interface and numerous sensors and modules. Additionally, it introduces a new power solution, allowing the use of a 7~12V power supply to power the board and devices via DC 2.1 or DC terminal port, with a maximum output of 5A under 5V IO. Note: The two power terminals are connected; do not connect external power simultaneously. Avoid powering LattePanda via USB when using a 7~12V external power supply. View more What's Included 1x Gravity IO Expansion Shield for LattePanda Dimensions 70 x 68 mm (2.76 x 2.68 inches) Specifications Compatible with LattePanda V1 (not with LattePanda Alpha & Delta) Compatible with Arduino Leonardo Compatible with Gravity sensor Input voltage range: 7V to 12V Input interface: DC 2.1; 2-pin wire Features 14 Digital Gravity interfaces Includes 6 Analog Gravity interfaces Equipped with 2 I2C ports Contains 1 ICSP port Output voltage fixed at 5V I/O operating voltage set at 5V Port maximum output current: 5A 3.3V port maximum output current: 1A Includes an 8x8 general 2.54mm prototype pad
