GMN L 80 x 100 x 10 Labyrinth Seal

Part Number L 80 x 100 x 10 Series L Drain Grooves No Inner Ring Material Steel Outer Ring Material Aluminum Dimensions  Inner Diameter ID [mm] 80 Outer Diameter OD [mm] 100 Width W [mm] 10 Geometric Data  Gap Diameter e [mm] 95 Axial Clearance Sax [mm] 0.420 Weight [kg] 0.160 Shaft & Housing Tolerances  Shaft & Housing Chamfer 1mm × 15° ID Tolerance h6 OD Tolerance K7 Shaft & Housing Surface Rz ≤ 16µm ; Ra ≤ 3.2µm Ratings  Max. Speed n [RPM] 14,500 Temperature Range [°C] -40 – 200
