Mitac MP1-11TGS-D Tiger Lake i3-1115G4E Fanless Industrial Embedded System, TPM 2.0

Manufacturer Mitac Product ID MP1-11TGS-D-1115G4E-AC CPU Intel Core i3-1115G4E Processor 2 Cores / 4 Threads 2.2 - 3.9 GHz 15W TDP, 6MB Cache Chipset SoC Memory 1 x DDR4-3200MHz SODIMM slot Maximum 32GB Capacity Non-ECC, Unbuffered Video Intel UHD Graphics1.25GHz DisplayPort Max Resolution: 3840x2160@60Hz HDMI Max Resolution: 4096x2304@24Hz Supports Quad Displays Audio Realtek ALC256 Storage Technology 1 x SATA3 6.0Gb/s 1 x M.2: PCI-E x1/USB/SATA3 Connectivity 1 x Intel I225-LM 2.5GbE LAN 1 x Intel I219-LM GbE LAN Expansion Slots 1 x M.2 2242/2260/2280/3042/3052 slot (B-Key)Note: Does not Support NVMe 1 x M.2 2230 slot (E Key, PCIe/USB) 2 x Xpansion slot (PoE/LAN/COM/DIO/IGN/CANBus) 1 x Mini PCI-E slot (full size, USB2.0/SATA/PCIe x1)Note: 5G card support is by BOM option. Please check with sales about the M.2 B Key 3052 5G card spec if you have any request Rear Panel I/O 2 x Antenna Holes 1 x 3-Pin Terminal Block Power Input 2 x DisplayPort 2 x H
