Acrison Volumetric Auger Feeder
$5,000.00
{{option.name}}:
{{selected_options[option.position]}}
{{value_obj.value}}
Acrison Volumetric Auger Feeder. Model: 1702-EE. S/N: 98135-01. GE motor, 1 hp, 1725 rpm, 115/230 V, 13.20/6.60 amps, 60 Hz, 1 phase. Comtrac motor drive, 106.1 ratio, 15.1 output rpm, 1580 output torque. Mixer with Baldor motor, 75 hp, 1750 rpm, 90 V, 7.9 amps. Ecoson motor drive, 15 ratio, 116 output rpm. Mixer flange: 4 in. W x 4 in. H with 3 hole, center to center: 8-1/2 in. Electric vibrator. SCR-DC Acrison Box control. Quick clean out port with 4-1/2 in diameter. Overall dimensions: 55 in. L x 31 in. W x 56 in H.
