Xilinx Field Programmable Gate Array | Part #: XC3S1000-4FT256I | FPGA | DEX

The Xilinx XC3S1000-4FT256I Spartan 3 family of Field-Programmable Gate Arrays is specifically designed to meet the needs of high volume, cost-sensitive consumer electronic applications. The eight-member family offers densities ranging from 50,000 to 5,000,000 system gatesFeatures• Low-cost, high-performance logic solution for high-volume,consumer-oriented applications• Densities up to 74,880 logic cells• SelectIO™ interface signaling• Up to 633 I/O pins• 622+ Mb/s data transfer rate per I/O• 18 single-ended signal standards• 8 differential I/O standards including LVDS, RSDS• Termination by Digitally Controlled Impedance• Signal swing ranging from 1.14V to 3.465V• Double Data Rate (DDR) support• DDR, DDR2 SDRAM support up to 333 Mb/s• Logic resources• Abundant logic cells with shift register capability• Wide, fast multiplexers• Fast look-ahead carry logic• Dedicated 18 x 18 multipliers• JTAG logic compatible with IEEE 1149.1/1532• SelectRAM™ hierarchical memory• Up to 1,872 Kbits of to
