Mitsubishi FR-CS82S-025-60
ddpartssolution.com

Mitsubishi FR-CS82S-025-60

$1,260.00
{{option.name}}: {{selected_options[option.position]}}
{{value_obj.value}}
Store Logo

DDPARTS SOLUTION

View Store

Mitsubishi FR-CS82S-025-60 Overview The Mitsubishi FR-CS82S-025-60 is a compact inverter drive in the FR-CS80 series, engineered to deliver 2.5 kW (3.3 HP) motor control for 3-phase 200V systems. Featuring advanced energy-saving functions, built-in RS-485 Modbus RTU, and integrated EMC filter, this inverter is ideal for small machines, conveyors, and fan/pump applications. Key Features Series: FR-CS80 Output Power: 2.5 kW (approx. 3.3 HP) Input Voltage: 3-phase 200–240 V AC Control Modes: V/F, V/F with PG, vector control Communications: RS-485 Modbus RTU (standard) Filter: Built-in EMC filter for noise reduction Enclosure: IP20 open type Display: 4-digit LED display with function keys Protection: Overload, overvoltage, undervoltage, and overheat Technical Specifications Model Number: FR-CS82S-025-60 Rated Output: 2.5 kW Max Output Current: Approx. 12 A Input Voltage Range: 200–240 V ±10% Frequency Range: 0.2 to 400 Hz Carrier Frequency: Up to 15 kHz (a
