ProSoft MVI56E-MCMR Interface Module In Stock

The Prosoft MVI56E-MCMR is a Modbus Master/Slave Communications Interface Module with Reduced Data Block for ControlLogix processors. It enables seamless communication between Rockwell Automation ControlLogix processors and devices that utilize the Modbus RTU/ASCII serial communications protocol. The MVI56E-MCMR employs a reduced Input/Output (I/O) data block for data transfer between itself and a ControlLogix processor, ensuring efficient data exchange. Specifications: Processor: ARM Cortex-A8 Clock speed: 800 MHz Memory: 128 MB SDRAM Storage: 128 MB NAND Flash Serial ports: 2 (RS-485, RS-232) Modbus protocols: Modbus RTU Master, Modbus RTU Slave, Modbus ASCII Master, Modbus ASCII Slave Data transfer rate: Up to 115,200 bps Dimensions: 17.8 cm x 11.4 cm x 2.5 cm Weight: 0.8 kg Operating temperature range: 0 to 55 degrees Celsius Storage temperature range: -25 to 70 degrees Celsius Relative humidity: 5 to 95% non-condensing Vibration: 5 g @ 10 to 500 Hz Shock: 10 g for 11 ms
